D-Cut and W-Cut Non Woven Bag Making Machine



Non Woven Bag Machine Introduction:
This machine adopts mechanical,electrical,optical and pneumatic integration technology, suitable for non-woven fabric, different specs of flat bag,D-cut bag,bottom/side gusset bag, vest bag and drawstring bags etc(used for shopping bag, gift bag,cloths bag ,shoes bag)can be made by this machine.
Non Woven Bag Machine Specification:
1. Fashion Non Woven Bag Making Machine.
2. Welcome customize design.
3. Fine craftsmanship,high quality standard.
4. High Production Speed.
5. Full automatic machine,save labor.
Non Woven Bag Machine Advantage:
1. Environment products.
2. Latest design in 2016,can make bag with handle in directly.
3. Taiwan PLC touch screen operation.
4. Computer sutomatic positioning.
5. Match with stepping type length setting.
Technical Specifications
Type | TMNW-B700 |
Production Speed | 20-120pcs/min |
Bag Width | 100-800mm |
Bag Height | 200-600mm |
Material Basis Weight | 30-120g/㎡ |
Power Supply | 380V/220V |
Total Power | 12KW |
Overall Dimension | 7600×1900×2100mm |
Weight | 2000KG |
