Cast Film Line 2000mm (Stretch Film Machine)
BASIC INFO
| Model No | TPCL-80/100/80C |
| Description | 2000mm 3/5 Layers Stretch Film Machine |
| Delivery Time | 80 Days |
| Width Of Die Head | 2350mm |
| Width Of Product Film | 2000mm |
| Linear Speed Of Machinery | 200m/min |
| Max Extrusion Capacity | 420kg/h |
| Actual Electric Consumption | 80-100KW |
| Actual Output | 7 Ton / 24 Hrs. |
| Motor Power Of Main Machine | 45/90/45 KW |
Product Description
TPCL-80/100/80C Automatic Plastic Wrapping Film Machinery
Main Technical Parameter
Width of Film: 2000mm
Thickness of Film: 0.01-0.05mm
Structure of Film Layers: A/B/C or A/C/B/C/A
Liner Speed of Machinery: 200m/min
Max Extrusion Capacity: 420kg/h
Max Rewind Diameter: 400mm
Screw Diameter: A:80mm
B:100mm
C:80mm
L/D Ratio of Screw: 30:1
Motor Power of Main Machine: 45/90/45kw
Overall Dimensions(L*W*H): 12*5.6*4.5m
Total Power: 100-250kw
Total Weight: 17T
Features of Plastic Melt Metering Pump for TPCL-80/100/80C Automatic Plastic Wrapping Film Machinery
STABLE AND EFFICIENCY PRESSURE CONTROL
The melt pump can provide a stable pressure, which short the discharge time obviously and make the production effectively.
INCREASE THE EXTRUDER OUTPUT AND THE MACHINE LIFE
It has been found that after install the melt pump, the max pressure wave value is the pressure after pump. Which can make the inner pressure of the extruder decrease, the melt shear strength decrease, the temperature curve gently, and restrain the temperature rising. Also the melt pump can avoid the damage to the extruder from the high pressure.
